1 |
23211K23900 |
MAINSHAFT(11T) |
1 |
2 |
23221KWS900 |
COUNTERSHAFT |
1 |
3 |
23415KPH900 |
BUSH, 15MM |
1 |
4 |
23421K23900 |
GEAR, COUNTERSHAFT FIRST(35T) |
1 |
5 |
23431K14900 |
GEAR, MAINSHAFT SECOND(17T) |
1 |
6 |
23441K14900 |
GEAR, COUNTERSHAFT SECOND(30T) |
1 |
7 |
23451K14900 |
GEAR, MAINSHAFT THIRD(21T) |
1 |
8 |
23461K14901 |
GEAR, COUNTERSHAFT THIRD(25T) |
1 |
9 |
23471K14900 |
GEAR, MAINSHAFT FOURTH(24T) |
1 |
10 |
23481KZAW00 |
GEAR, COUNTERSHAFT FOURTH(22T) |
1 |
11 |
23801KWB600 |
SPROCKET, DRIVE(14T) |
1 |
12 |
23802GN5910 |
PLATE, FIXING |
1 |
13 |
23911KZAW00 |
COLLAR, 20MM |
1 |
14 |
90412187000 |
WASHER, THRUST, 15MM |
1 |
15 |
90412KPH900 |
WASHER, SPECIAL, 12X23 |
2 |
16 |
90461035000 |
WASHER, SPLINE, 17MM |
2 |
17 |
90461459010 |
WASHER, SPLINE, 20MM |
1 |
18 |
90601459000 |
CIRCLIP, 20MM |
1 |
19 |
90601KRM840 |
CIRCLIP, 17MM |
2 |
20 |
91004KWS901 |
BEARING, RADIAL BALL, 6201(FAG) |
1 |
21 |
91004K14901 |
BEARING, RADIAL BALL, 6201(NEI) |
1 |
22 |
91005K14901 |
BEARING, BALL RADIAL, 6001(NEI) |
1 |
23 |
91005KWS901 |
BEARING, RADIAL BALL, 6001(FAG) |
1 |
24 |
91006K14901 |
BEARING, RADIAL BALL, 6203 (SKF) |
2 |
25 |
91006K14902 |
BEARING, RADIAL BALL, 6203 (FAG) |
2 |
26 |
91204KWB601 |
OIL SEAL, 17X29X5 |
1 |
27 |
93101060100A |
BOLT, HEX., 6X10 |
2 |
28 |
23221K63D30 |
COUNTERSHAFT |
1 |
29 |
23421K55600 |
GEAR, COUNTERSHAFT FIRST(35T) |
1 |
30 |
23431K55600 |
GEAR, MAINSHAFT SECOND(17T) |
1 |
31 |
23441K55600 |
GEAR, COUNTERSHAFT SECOND(30T) |
1 |
32 |
23451K55600 |
GEAR, MAINSHAFT THIRD(21T) |
1 |
33 |
23461K55600 |
GEAR, COUNTERSHAFT THIRD(25T) |
1 |
34 |
23471K55600 |
GEAR, MAINSHAFT FOURTH(24T) |
1 |
35 |
23481K55600 |
GEAR, COUNTERSHAFT FOURTH(22T) |
1 |
36 |
90412KPH900 |
WASHER, SPECIAL, 12X23 |
1 |
37 |
91007K63D31 |
BEARING, NEEDLE, 14X22X13 (SCHAEFFLER) |
1 |
38 |
90412K63D30 |
WASHER, SPECIAL, 14X26 |
1 |
39 |
91007K63D32 |
BEARING, NEEDLE, 14X22X13(NRB) |
1 |
