Scooters Activa i SCV110HH Frame Kick starter arm/stand
Ref.No. Part No. Description Oty
1 28300K32700 ARM ASSY., KICK STARTER 1
2 28300KVT900 ARM ASSY., KICK STARTER 1
3 50500K32900 STAND COMP., MAIN 1
4 50503GCC000 SHAFT, MAIN STAND 1
5 50505GCC000 SPRING ASSY., MAIN STAND 1
6 50505KWPE00 SPRING ASSY., MAIN STAND 1
7 50530K32900 BAR COMP., SIDE STAND 1
8 50532KWPD00 COLLAR, SIDE STAND 2
9 50535KWPD00 BRACKET, SIDE STAND 1
10 50536KPL900 SPRING, SIDE STAND 1
11 50560K32900 STAND SET, SIDE 1
12 90109KPL900 BOLT, SIDE STAND PIVOT 1
13 90304KTE911 NUT, FLANGE SPECIAL, 10MM (SIMMODS MARSHALL) 1
14 9410212000 WASHER, PLAIN, 12MM 1
15 9420125250 PIN, SPLIT, 2.5X25 1
16 957010802507 BOLT, FLANGE, 8X25 1
17 958021007007 BOLT, FLANGE, 10X70 2
18 958011007007 BOLT, FLANGE, 10X70 2
