Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 61000K43910ZH | FENDER SET A, FR.(WL)*TYPE3* | 1 |
2 | 61000K43910ZJ | FENDER SET A, FR.(WL)*TYPE2* | 1 |
3 | 61000K43910ZG | FENDER SET A, FR.(WL)*TYPE4* | 1 |
4 | 61000K43910ZK | FENDER SET A, FR.(WL)*TYPE1* | 1 |
5 | 61000K43910ZF | FENDER SET A, FR.(WL)*TYPE5* | 1 |
6 | 61103KRY900 | COLLAR A, FR. FENDER | 6 |
7 | 61105KRY900 | RUBBER, FR. FENDER MOUNTING | 6 |
8 | 61111K43900ZC | FENDER A, FR. *PB123PA* PEARL SIREN BLUE-A | 1 |
9 | 61111K43900ZB | FENDER A, FR. *R321* SPORTS RED | 1 |
10 | 61111K43900ZD | FENDER A, FR. *NHB63P* PEARL AMAZING WHITE | 1 |
11 | 61111K43900ZA | FENDER A, FR. *YR302M* NEO ORANGE METALLIC | 1 |
12 | 61111K43900ZE | FENDER A, FR. *NHA84P* PEARL NIGHTSTAR BLACK | 1 |
13 | 61121K43900 | FENDER B, FR. | 1 |
14 | 90130KYJ900 | SCREW, PAN, 6X22 | 4 |
15 | 90131KYJ900 | BOLT, FLANGE, 6X22 | 2 |
16 | 90485286000 | WASHER, 6MM | 2 |
17 | 9390325280 | SCREW, TAPPING, 5X12 | 4 |
