| Ref.No. | Part No. | Description | Oty |
|---|---|---|---|
| 1 | 16574ZG8300 | SPRING, LEVER | 1 |
| 2 | 50400KTE650ZA | GRIP, RR. *YR305M* MAPLE BROWN METALLIC | 1 |
| 3 | 50400KTE650ZC | GRIP, RR. *NH1* BLACK | 1 |
| 4 | 50400KTE650ZG | GRIP,RR.*R329M*....REBEL RED METALLIC | 1 |
| 5 | 50400KTE650ZF | GRIP, RR. *R355M* IMPERIAL RED METALLIC | 1 |
| 6 | 50400KTE650ZD | GRIP, RR. *NHB63P* PEARL AMAZING WHITE | 1 |
| 7 | 50400KTE650ZH | GRIP,RR.*R321*SPORTS RED | 1 |
| 8 | 50400KTE650ZE | GRIP, RR. *NHA04M* GENY GRAY METALLIC | 1 |
| 9 | 75581GN8920 | SPRING, LOCK KEY SETTING | 1 |
| 10 | 77156KTE910 | CABLE, SEAT LOCK | 1 |
| 11 | 77200KTE651ZA | SEAT ASSY., DOUBLE(VARROC) *TYPE1* | 1 |
| 12 | 77200KTE652ZA | SEAT ASSY., DOUBLE(TS TECH) *TYPE1* | 1 |
| 13 | 77204KCC900 | RUBBER A, SEAT SETTING | 2 |
| 14 | 77206KTE910 | RUBBER, SEAT SETTING | 4 |
| 15 | 77225KTE911 | LOCK ASSY., SEAT | 1 |
| 16 | 77235KTE910 | CATCH COMP., SEAT | 1 |
| 17 | 77251KPL900 | BAG, SERVICE BOOK | 1 |
| 18 | 957010601200 | BOLT, FLANGE, 6X12 | 2 |
| 19 | 957020601200 | BOLT, FLANGE, 6X12 | 2 |
| 20 | 957010802000 | BOLT, FLANGE, 8X20 | 4 |
| 21 | 957020802000 | BOLT, FLANGE, 8X20 | 4 |
