Motorcycles CBF Stunner CBF125M9/MF Engine Right crankcase cover
Ref.No. Part No. Description Oty
1 11330KWF960 COVER COMP., R. CRANKCASE 1
2 11330KWF900 COVER COMP., R. CRANKCASE 1
3 11393KRM840 GASKET, R. CRANKCASE COVER 1
4 15651KWF900 GAUGE, OIL LEVEL 1
5 22810KWF940 LEVER COMP., CLUTCH 1
6 22810KRMB00 LEVER COMP., CLUTCH 1
7 22810KWF900 LEVER COMP., CLUTCH 1
8 22815428000 SPRING, CLUTCH LEVER 1
9 22821KRM840 RECEIVER, CLUTCH CABLE 1
10 22821KWF940 RECEIVER, CLUTCH CABLE 1
11 91105KSP910 DOWEL PIN, 8X14 2
12 91202KSP911 OIL SEAL, 12X18X4 1
13 91204KSP911 OIL SEAL, 16X28X7 1
14 91307KRM840 O-RING, 18X3 1
15 9430530102 PIN, SPRING, 3X10 1
16 960010603000 BOLT, FLANGE, 6X30 3
17 90013KWF940 BOLT, FLANGE, 6X30 3
18 960010604000 BOLT, FLANGE, 6X40 9
19 90010KWF940 BOLT, FLANGE, 6X40 9
