Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 50400KWF900ZK | GRIP, RR. *R101CU* CANDY GLORY RED-U | 1 |
2 | 50400KWF900ZQ | GRIP, RR. *PB332P* PEARL HERON BLUE | 1 |
3 | 64122KV0000 | RUBBER B, SIDE SHELTER | 2 |
4 | 75581GN8920 | SPRING, LOCK KEY SETTING | 1 |
5 | 77100KWF900 | SEAT COMP., SINGLE | 1 |
6 | 77204KCC900 | RUBBER A, SEAT SETTING | 4 |
7 | 77205286000 | RUBBER B, SEAT SETTING | 2 |
8 | 77206KFN850 | RUBBER, SEAT CUSHION | 2 |
9 | 77207KWF900 | COLLAR, SEAT MOUNTING | 2 |
10 | 77225KWF901 | LOCK ASSY., SEAT | 1 |
11 | 77235KWF900 | CATCH COMP., SEAT | 1 |
12 | 77236GBL000 | SPRING, SEAT CATCH | 1 |
13 | 77251KPL900 | BAG, SERVICE BOOK | 1 |
14 | 77300KWF900 | SEAT COMP., PILLION | 1 |
15 | 81202KWF900 | COLLAR, CARRIER | 4 |
16 | 957010602508 | BOLT, FLANGE, 6X25 | 2 |
17 | 957020602508 | BOLT, FLANGE, 6X25 | 2 |
18 | 957010802500 | BOLT, FLANGE, 8X25 | 4 |
19 | 957020802500 | BOLT, FLANGE, 8X25 | 4 |
