Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 31500KRP902 | BATTERY(AB5L-B) | 1 |
2 | 31502KSP920 | TUBE, BATTERY BREATHER | 1 |
3 | 32401KTE930 | CABLE, STARTER MAGNETIC BATTERY | 1 |
4 | 32406KAZ000 | COVER, STARTER MAGNETIC TERMINAL | 1 |
5 | 32410KTE930 | CABLE, STARTER MOTOR | 1 |
6 | 32411253000 | COVER, STARTER MOTOR TERMINAL | 1 |
7 | 32414KTC920 | COVER, BATTERY TERMINAL | 1 |
8 | 32601KTE930 | CABLE, BATTERY EARTH | 1 |
9 | 35850KEB620 | SWITCH ASSY., STARTER MAGNETIC | 1 |
10 | 35856KTE930 | RUBBER, SHOCK | 1 |
11 | 38201KTE930 | HOLDER, FUSE | 1 |
12 | 50380KTE930 | BOX COMP., BATTERY | 1 |
13 | 50383GB6300 | RUBBER, BATTERY | 1 |
14 | 50385KTE930 | TRAY, BATTERY | 1 |
15 | 50386KTE930 | COVER, BATTERY | 1 |
16 | 50388KTE930 | TUBE, BATTERY TRAY | 1 |
17 | 90101GE0000 | SCREW, HINGE PATCH | 1 |
18 | 90111MR5000 | BOLT, SOCKET, 5X9 | 2 |
19 | 90602KPL900 | CLAMP, TUBE(D12.0) | 1 |
20 | 92301060120A | BOLT, RECESSED, 6X12 | 1 |
21 | 9410106800 | WASHER, PLAIN, 6MM | 1 |
22 | 957010601000 | BOLT, FLANGE, 6X10 | 3 |
23 | 9820032000 | FUSE, BLADE(20A) | 2 |
