Motorcycles CB Shine CBF125C9 Engine Cylinder
Ref.No. Part No. Description Oty
1 12100KTE910 CYLINDER COMP. 1
2 12100KWF960 CYLINDER COMP. 1
3 12100KWF900 CYLINDER COMP. 1
4 12100KTEA00 CYLINDER COMP. 1
5 12191KSP910 GASKET, CYLINDER 1
6 12191KWK900 GASKET, CYLINDER 1
7 12195KTE910 RUBBER, INSERT 3
8 91106KSP910 DOWEL PIN, 10X12 2
9 90703KRM840 DOWEL PIN, 10X12 2
