Scooters Activa i SCV110HE Frame Front fender
Ref.No. Part No. Description Oty
1 61000K32900ZD FENDER SET, FR.(WL)*TYPE1* 1
2 61000K32900ZB FENDER SET, FR.(WL)*TYPE3* 1
3 61000K32900ZC FENDER SET, FR.(WL)*TYPE2* 1
4 61000K32900ZA FENDER SET, FR.(WL)*TYPE4* 1
5 61110K32900 FENDER B, FR. 1
6 90111187000 BOLT, FLANGE, 6MM 2
7 90113KRP900 BOLT, SPECIAL HEX., 6X14 2
