Scooters Activa SCV110D Frame Front cover(scv1109,b,d,e)
Ref.No. Part No. Description Oty
1 61104428010 COLLAR, FR. FENDER(WHITE)..... (FOR RR.) 1
2 50330KWPP20ZZ TRAY COMP., BATTERY 1
3 61104428010 COLLAR, FR. FENDER(WHITE)..... (FOR RR.) 2
4 64200KWP900ZA COVER SET, FR. CENTER(WL) *NHA04M* GENY GRAY METALLIC 1
5 64200KWP900ZC COVER SET, FR. CENTER(WL) *NH1* BLACK 1
6 64200KWP900ZE COVER SET, FR. CENTER(WL) *RP175M* WILD PURPLE METALLIC 1
7 64200KWP900ZN COVER SET, FR. CENTER(WL) *NHA66P* PEARL SUNBEAM WHITE 1
8 64200KWP900ZM COVER SET, FR. CENTER(WL) *R264C* CANDY LUCID RED 1
9 64303KWP900 STAY, FR. NUMBER PLATE 1
10 64304KWPP10ZZ COVER COMP., R. FR. 1
11 64305KWPP10ZZ COVER COMP., L. FR. 1
12 64306KWP900 GROMMET A, R. FR. COVER 1
13 64307KWP900 LOUVER, R. FR. COVER 1
14 64308KWP900 LOUVER, L. FR. COVER 1
15 64314KWP900 GROMMET B, FR. COVER 2
16 64316KWP900 GROMMET A, L. FR. COVER 1
17 81131KWP900ZA COVER, INNER *NH1* BLACK 1
18 84703425000 RUBBER, TAILLIGHT MOUNTING 2
19 90111KWP900 BOLT, INNER COVER 1
20 90344KRB900 NUT, CLIP, 5MM 10
21 90344KRP900 NUT, CLIP, 5MM 4
22 90666SDAA01 CLIP, SNAP FITTING(PO)(NATURAL) 4
23 9390325380 SCREW, TAPPING, 5X16 14
24 9405006080 NUT, FLANGE, 6MM 2
25 957020601208 BOLT, FLANGE, 6X12 3
26 957010601208 BOLT, FLANGE, 6X12 3
27 957020602507 BOLT, FLANGE, 6X25 2
28 957010602507 BOLT, FLANGE, 6X25 2
29 958010601008 BOLT, FLANGE, 6X10 4
30 958020601008 BOLT, FLANGE, 6X10 4
31 9390325280 SCREW, TAPPING, 5X12 4
32 50381KWPD00 CASE, BATTERY 1
