Motorcycles CB Twister CBF110ME Frame Frame body
Ref.No. Part No. Description Oty
1 50100KWS901 BODY COMP., FRAME 1
2 50351KWS910 PLATE, FR. ENGINE HANGER 1
3 50400KWSB00 GRIP, RR. 1
4 90019399010 BOLT, FLANGE, 10X110 2
5 9405008000 NUT, FLANGE, 8MM 2
6 9405010000 NUT, FLANGE, 10MM 4
7 957010801608 BOLT, FLANGE, 8X16 4
8 957020801608 BOLT, FLANGE, 8X16 4
9 958010806000 BOLT, FLANGE, 8X60 4
10 958020806000 BOLT, FLANGE, 8X60 4
11 958011008500 BOLT, FLANGE, 10X85 1
12 958021008500 BOLT, FLANGE, 10X85 1
13 958011009500 BOLT, FLANGE, 10X95 1
14 958021009500 BOLT, FLANGE, 10X95 1
