Scooters Activa SCV110B Frame Front cover(scv1109,b,d,e)
Ref.No. Part No. Description Oty
1 50330KWPP10ZZ TRAY COMP., BATTERY 1
2 61104428010 COLLAR, FR. FENDER(WHITE)..... (FOR RR.) 1
3 61104428010 COLLAR, FR. FENDER(WHITE)..... (FOR RR.) 2
4 64200KWP900ZA COVER SET, FR. CENTER(WL) *NHA04M* GENY GRAY METALLIC 1
5 64200KWP900ZB COVER SET, FR. CENTER(WL) *NHA66P* PEARL SUNBEAM WHITE 1
6 64200KWP900ZC COVER SET, FR. CENTER(WL) *NH1* BLACK 1
7 64200KWP900ZF COVER SET, FR. CENTER(WL) *R264C* CANDY LUCID RED 1
8 64200KWP900ZG COVER SET, FR. CENTER(WL) *B213M* ORCHID BLUE METALLIC 1
9 64200KWP900ZH COVER SET, FR. CENTER(WL) *Y207M* ARMOUR GOLD METALLIC 1
10 64303KWP900 STAY, FR. NUMBER PLATE 1
11 64304KWPP00ZZ COVER COMP., R. FR. 1
12 64305KWPP00ZZ COVER COMP., L. FR. 1
13 64306KWP900 GROMMET A, R. FR. COVER 1
14 64307KWP900 LOUVER, R. FR. COVER 1
15 64308KWP900 LOUVER, L. FR. COVER 1
16 64314KWP900 GROMMET B, FR. COVER 2
17 64316KWP900 GROMMET A, L. FR. COVER 1
18 81131KWP900ZA COVER, INNER *NH1* BLACK 1
19 81136KWP900 CAP, SWITCH 1
20 84703425000 RUBBER, TAILLIGHT MOUNTING 2
21 90111KWP900 BOLT, INNER COVER 2
22 90111KWP900 BOLT, INNER COVER 1
23 90344KRB900 NUT, CLIP, 5MM 10
24 90344KRP900 NUT, CLIP, 5MM 4
25 90666SDAA01 CLIP, SNAP FITTING(PO)(NATURAL) 4
26 9390325380 SCREW, TAPPING, 5X16 14
27 9405006080 NUT, FLANGE, 6MM 2
28 957020601208 BOLT, FLANGE, 6X12 3
29 957010601208 BOLT, FLANGE, 6X12 3
30 957020602507 BOLT, FLANGE, 6X25 2
31 957010602507 BOLT, FLANGE, 6X25 2
32 958010601008 BOLT, FLANGE, 6X10 4
33 958020601008 BOLT, FLANGE, 6X10 4
34 9390325280 SCREW, TAPPING, 5X12 4
