Scooters Activa SCV110B Frame Front wheel(scv100cm2,5/scv1109,b)
Ref.No. Part No. Description Oty
1 06430KWP900 SHOE SET, BRAKE(JB) 1
2 06430KTC900 SHOE SET, BRAKE 1
3 42711KWP911 TYRE(MRF)(90/100-10 53J) 1
4 42711KRB904 TIRE(MRF)(90/100-10 53J) 1
5 45141KWP900 CAM, FR. BRAKE 1
6 45141KWP910 CAM, FR. BRAKE 1
7 44301KPL900 AXLE, FR. WHEEL 1
8 44311KPL900 COLLAR, FR. WHEEL SIDE 1
9 44620KPL900 COLLAR, FR. AXLE DISTANCE 1
10 44650KWP900 WHEEL SUB ASSY., FR. 1
11 44809KPL900 WASHER, SPEEDOMETER GEAR 1
12 44811KPL900 GEAR, SPEEDOMETER 1
13 45134250000 DUST SEAL, BRAKE CAM 1
14 45145KPL900 INDICATOR, FR. BRAKE 1
15 45410KPL900 ARM, FR. BRAKE 1
16 45435KPL900 SPRING, BRAKE ARM RETURN 1
17 90306KST942 NUT, FLANGE, 12MM (LEO FASTENERS) 1
18 90306KTE911 NUT, FLANGE SPECIAL, 12MM (SIMMONDS MARSHALL) 1
19 91251KWP901 DUST SEAL, 20X32X5 1
20 90912KPL900 BEARING, RADIAL BALL, 6201U 2
21 91253KPL900 DUST SEAL, 41X60X7 1
22 9405006000 NUT, FLANGE, 6MM 1
23 9501532001 JOINT B, BRAKE ARM 1
24 9501542000 NUT B, BRAKE ROD ADJUSTING 1
25 957020603200 BOLT, FLANGE, 6X32 1
26 957010603200 BOLT, FLANGE, 6X32 1
27 957020603500 BOLT, FLANGE, 6X35 1
28 957010603500 BOLT, FLANGE, 6X35 1
29 45133KPL900 SPRING, FR.BRAKE SHOE (ASK)(FOR RR.) 2
30 42712KRB903 TUBE, TIRE(MRF)(90/100-10) 1
31 45010KWP900 PANEL SUB COMP., FR. BRAKE 1
32 45010KWP910 PANEL SUB COMP., FR. BRAKE 1
33 45410KWP910 ARM COMP., FR. BRAKE 1
34 45415KWP910 COVER, BRAKE ARM 1
35 45416KWP910 COLLAR, BRAKE ARM COVER 1
36 45453KWP911 JOINT, BRAKE ARM 2
37 45456KWP910 SPRING, BRAKE CABLE END 2
38 45459KWP911 NUT, BRAKE ADJUSTING 2
39 93500050101G SCREW, PAN, 5X10 1
40 44820KWP900 GEAR SET, SPEEDOMETER 1
