Scooters Activa SCV100CM5 Frame Spare tire set
Ref.No. Part No. Description Oty
1 06427KPL840 TUBE SET, TUFF UP 1
2 42702KPL900 RIM COMP., WHEEL 1
3 42711KRB904 TIRE(MRF)(90/100-10 53J) 1
4 81210KPL900 BRACKET, SPARE TIRE 1
5 81211KPL900 COLLAR, 15X27.5 1
6 81212KPL900 RUBBER, SPARE TIRE BRACKET 1
7 81213KPL900 BAND, SPARE TIRE BRACKET 1
8 90309KPL900 NUT, SPECIAL FLANGE, 8MM 3
9 9405008080 NUT, FLANGE, 8MM 1
10 958010801608 BOLT, FLANGE, 8X16 1
11 958010805008 BOLT, FLANGE, 8X50 1
12 960010602000 BOLT, FLANGE, 6X20 2
13 06812KPL900 BRACKET SET, SPARE TIRE 1
