Scooters Activa SCV100CM5 Frame Battery(scv100cm2,5)
Ref.No. Part No. Description Oty
1 31500KRP901 BATTERY(12MX5L-B) 1
2 31500KRP902 BATTERY(AB5L-B) 1
3 31502KRP900 TUBE, BATTERY BREATHER 1
4 50325KPL900 BOX, BATTERY UPPER 1
5 50326KPL900 BOX, BATTERY LOWER 1
6 50336KPL900 BAND COMP., BATTERY 1
7 957010601208 BOLT, FLANGE, 6X12 1
