Scooters Activa125 SCV125L Frame Rear combination light
Ref.No. Part No. Description Oty
1 33710K0LD01 LIGHT UNIT, RR. COMBINATION 1
2 33715K0LD01 SOCKET COMP. 1
3 34907KVN901 BULB, TAIL & STOP LIGHT (12V 21/5W) 1
4 34930KWA930 BULB, WINKER(12V 10W)(AMBER) 2
5 91509GE2760 SCREW, PAN, 5X11.5 6
6 91558K0LD01 CLIP, WIRE HARNESS 1
7 9390334480 SCREW, TAPPING, 4X16 2
8 9390335380 SCREW, TAPPING, 5X16 2
