Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 06430KWP900 | SHOE SET, BRAKE(JB) | 1 |
2 | 06430KWPD00 | SHOE SET, BRAKE(ASK) | 1 |
3 | 42650K0LD00ZA | WHEEL SUB ASSY., RR. *NH35M* CLOUD SILVER METALLIC | 1 |
4 | 42711KZK902 | TIRE(TVS)(90/100-10M/C 53J) | 1 |
5 | 42711KZK901 | TIRE(MRF)(90/100-10M/C 53J) | 1 |
6 | 42711KWPF01 | TIRE(CEAT)(90/100-10 53J) | 1 |
7 | 42711KWPG01 | TIRE(MAXXIS)(90/100-10 53J) | 1 |
8 | 42753KWPE01 | VALVE, RIM(TRITON) | 1 |
9 | 42753K24G01 | VALVE, RIM(ACCURA) | 1 |
10 | 43141K0LD00 | CAM, RR. BRAKE | 1 |
11 | 43410K0LD00 | ARM, RR. BRAKE | 1 |
12 | 43472KPL900 | SPRING, RR. BRAKE ARM | 1 |
13 | 45133KPL900 | SPRING, FR.BRAKE SHOE (ASK)(FOR RR.) | 2 |
14 | 90112KPL900 | BOLT, FLANGE, 6X30 | 1 |
15 | 90305KWP901 | NUT, HEX., 16MM | 1 |
16 | 90501KPL900 | WASHER, 16MM | 1 |
17 | 9501532001 | JOINT B, BRAKE ARM | 1 |
18 | 9501542000 | NUT B, BRAKE ROD ADJUSTING | 1 |
