| Ref.No. | Part No. | Description | Oty |
|---|---|---|---|
| 1 | 13000K0LD00 | CRANKSHAFT COMP. | 1 |
| 2 | 13021K0LD00 | RING SET, PISTON(O.S. 0.25) | 1 |
| 3 | 13011K0LD00 | RING SET, PISTON(STD.) | 1 |
| 4 | 13031K0LD00 | RING SET, PISTON(O.S. 0.50) | 1 |
| 5 | 13051K0LD00 | RING SET, PISTON(O.S. 1.00) | 1 |
| 6 | 13041K0LD00 | RING SET, PISTON(O.S. 0.75) | 1 |
| 7 | 13103K0LD00 | PISTON(O.S. 0.50) | 1 |
| 8 | 13105K0LD00 | PISTON(O.S. 1.00) | 1 |
| 9 | 13102K0LD00 | PISTON(O.S. 0.25) | 1 |
| 10 | 13101K0LD00 | PISTON(STD.) | 1 |
| 11 | 13104K0LD00 | PISTON(O.S. 0.75) | 1 |
| 12 | 13111K0JN00 | PIN, PISTON | 1 |
| 13 | 13115K23900 | CLIP, PISTON PIN, 12MM | 2 |
| 14 | 90741K0LD00 | KEY, WOODRUFF, 4MM | 1 |
