Motorcycles CB Hornet 160R CBF160MAK Frame Fuel tank cover
Ref.No. Part No. Description Oty
1 64412K43900 SPONGE, FUEL TANK SIDE COVER RUBBER 2
2 64413K43900 FILM, FUEL TANK COVER PROTECTOR(R.) 1
3 64413KSSC00 GROMMET, BODY COVER 6
4 64415K43D60ZA COVER ASSY., R. FUEL TANK *TYPE5* 1
5 64415K43D40ZD COVER ASSY., R. FUEL TANK (WITH EMBLEM & STRIPE) *TYPE1* 1
6 64415K43D60ZE COVER ASSY., R. FUEL TANK *TYPE1* 1
7 64415K43D40ZC COVER ASSY., R. FUEL TANK (WITH EMBLEM & STRIPE) *TYPE2* 1
8 64415K43D40ZB COVER ASSY., R. FUEL TANK (WITH EMBLEM & STRIPE) *TYPE3*...................... 1
9 64415K43D60ZB COVER ASSY., R. FUEL TANK *TYPE4* 1
10 64415K43D40ZA COVER ASSY., R. FUEL TANK (WITH EMBLEM & STRIPE) *TYPE4* 1
11 64415K43D60ZD COVER ASSY., R. FUEL TANK *TYPE2* 1
12 64415K43D60ZC COVER ASSY., R. FUEL TANK *TYPE3* 1
13 64423K43900 FILM, FUEL TANK COVER PROTECTOR(L.) 1
14 64425K43D40ZA COVER ASSY., L. FUEL TANK (WITH EMBLEM & STRIPE) *TYPE4* 1
15 64425K43D60ZB COVER ASSY., L. FUEL TANK *TYPE4* 1
16 64425K43D60ZC COVER ASSY., L. FUEL TANK *TYPE3* 1
17 64425K43D60ZD COVER ASSY., L. FUEL TANK *TYPE2* 1
18 64425K43D40ZC COVER ASSY., L. FUEL TANK (WITH EMBLEM & STRIPE) *TYPE2* 1
19 64425K43D40ZD COVER ASSY., L. FUEL TANK (WITH EMBLEM & STRIPE) *TYPE1* 1
20 64425K43D60ZA COVER ASSY., L. FUEL TANK *TYPE5* 1
21 64425K43D60ZE COVER ASSY., L. FUEL TANK *TYPE1* 1
22 64425K43D40ZB COVER ASSY., L. FUEL TANK (WITH EMBLEM & STRIPE) *TYPE3*. 1
23 64431K43900 COVER, FUEL TANK CENTER 1
24 64432K43900 SPONGE, FUEL TANK CENTER COVER RUBBER 1
25 64461K43900 COVER, R. FUEL TANK INNER 1
26 64471K43900 COVER, L. FUEL TANK INNER 1
27 83551376000 GROMMET, SIDE COVER 2
28 83551GE2000 GROMMET, AIR CLEANER CASE 6
29 86201K43900 EMBLEM, R. WING(95MM) 1
30 86202K43900 EMBLEM, L. WING(95MM) 1
31 90116SP0003 CLIP, BUMPER SEAL 2
32 90320KTE600 NUT, SPRING, 5MM 2
33 91509GE2760 SCREW, PAN, 5X11.5 7
34 9390325280 SCREW, TAPPING, 5X12 8
