Motorcycles CB Unicorn CBF150M7 Frame Front wheel(spoke)
Ref.No. Part No. Description Oty
1 06440KFN850 SPOKE SET A, FR.(OUTSIDE) 18
2 06441KFN850 SPOKE SET B, FR.(INSIDE) 18
3 42713KSP901 FLAP, TIRE(1.60/1.85-18) 1
4 44301KSP900 AXLE, FR. WHEEL 1
5 44311KSP900 COLLAR, FR. WHEEL SIDE 1
6 44620KSP900 COLLAR, FR. AXLE DISTANCE 1
7 44635KSP930ZB HUB SUB ASSY., FR. *NH105* MAT BLACK(#15-#20) 1
8 44650KSP930ZB WHEEL SUB ASSY., FR. *NH105* MAT BLACK(#15-#20) 1
9 44680410000 RETAINER, GEAR BOX 1
10 44701KSP930 RIM, FR. WHEEL 1
11 44711KFN852 TIRE, FR.(2.75-18 42P) 1
12 44712KFN852 TUBE(2.75-18) 1
13 44800KSP900ZC BOX ASSY., SPEEDOMETER GEAR *NH105* MAT BLACK(#15-#20) 1
14 44804KSP901 GEAR, SPEEDOMETER 1
15 44809KPL900 WASHER, SPEEDOMETER GEAR 1
16 90306KTE911 NUT, FLANGE SPECIAL, 12MM (SIMMONDS MARSHALL) 1
17 91251KPH901 DUST SEAL, 21X37X7(ARAI) 1
18 91258410013 DUST SEAL, 40X50X5(ARAI) 1
19 961406301010 BEARING, RADIAL BALL, 6301U 2
20 45122KSP930ZB HUB, FR. BRAKE *NH105* MAT BLACK(#15-#20) 1
21 45251KSP861 DISK, FR. BRAKE(YUTAKA) 1
22 90105KSP930 BOLT, DISK, 8X22 6
23 90301KGH901 NUT, U, 6MM(FUJI SEIMITSU) 5
24 92911060180E BOLT, STUD, 6X18 5
