Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 13000K24G00 | CRANKSHAFT COMP. | 1 |
2 | 13031K24900 | RING SET, PISTON(0.50)(RIKEN) | 1 |
3 | 13011K24900 | RING SET, PISTON(RIKEN) | 1 |
4 | 13051K24900 | RING SET, PISTON(1.00)(RIKEN) | 1 |
5 | 13021K24900 | RING SET, PISTON(0.25)(RIKEN) | 1 |
6 | 13032K24900 | RING SET, PISTON(0.50)(TPR) | 1 |
7 | 13042K24900 | RING SET, PISTON(0.75)(TPR) | 1 |
8 | 13022K24900 | RING SET, PISTON(0.25)(TPR) | 1 |
9 | 13052K24900 | RING SET, PISTON(1.00)(TPR) | 1 |
10 | 13012K24900 | RING SET, PISTON(TPR) | 1 |
11 | 13041K24900 | RING SET, PISTON(0.75)(RIKEN) | 1 |
12 | 13102K24900 | PISTON(0.25) | 1 |
13 | 13101K24900 | PISTON | 1 |
14 | 13103K24900 | PISTON(0.50) | 1 |
15 | 13105K24900 | PISTON(1.00) | 1 |
16 | 13104K24900 | PISTON(0.75) | 1 |
17 | 13111KWN900 | PIN, PISTON | 1 |
18 | 13115001000 | CLIP, PISTON PIN | 2 |
19 | 90741KPL900 | KEY, WOODRUFF | 1 |
