Motorcycles Livo CBF110SBK Frame Rear fender
Ref.No. Part No. Description Oty
1 33741KPL902 REFLECTOR, REFLEX 1
2 80101K55600 STAY, TAILLIGHT 1
3 80110K55900ZA FENDER SET, RR(WL)*TYPE1* 1
4 83551KWS900 GROMMET, TAILLIGHT 1
5 90111162000 BOLT, FLANGE, 6MM 2
6 90301KWN901 NUT, U, 5MM 1
7 90311KTE910 NUT, RR. FENDER 2
8 90320GC3000 NUT, SPRING, 5MM 8
9 91509GE2760 SCREW, PAN, 5X11.5 2
