Motorcycles XBlade CBF160FSK Frame Headlight
Ref.No. Part No. Description Oty
1 33100K0ED01 HEADLIGHT ASSY. 1
2 61303K0ED00 COVER, HEADLIGHT RR. 1
3 61312K0ED00 STAY COMP., RR. HEADLIGHT COVER 1
4 90101GE0000 SCREW, HINGE PATCH 8
5 90111187000 BOLT, FLANGE, 6MM 2
6 90320KTE600 NUT, SPRING, 5MM 4
7 9390325220 SCREW, TAPPING, 5X12 3
8 9390325320 SCREW, TAPPING, 5X16 2
9 957010601207 BOLT, FLANGE, 6X12 2
