Scooters Aviator SCV110GK Frame Seat/luggage box
Ref.No. Part No. Description Oty
1 77115KVT900 RUBBER, SEAL 1
2 77200KVTG01ZA SEAT COMP., DOUBLE *TYPE1* 1
3 77201KVT900 HINGE, SEAT 1
4 77203KVTJ00 STAY, HOOK LUGGAGE 1
5 77206KG8900 RUBBER, SEAT SETTING 2
6 77235K86D00 CATCH COMP., SEAT 1
7 77234K86D00 SPRING, SEAT LOCK 1
8 77251KPL900 BAG, SERVICE BOOK 1
9 81250KVTG00 BOX, LUGGAGE 1
10 81251KVTJ00ZA COVER, FUEL TANK *NH1* BLACK 1
11 81255KVT940 COVER, CARBURETOR MAINTENANCE 1
12 90105KTP900 PIN, HINGE 1
13 90112KRP900 BOLT, FLANGE, 6X18 2
14 90862KWPG00 PLUG, END 1
15 934040601207 BOLT-WASHER, 6X12 4
16 9390325380 SCREW, TAPPING, 5X16 6
17 9405006000 NUT, FLANGE, 6MM 2
18 957010601608 BOLT, FLANGE, 6X16 2
19 77240KWPH01 CABLE COMP., SEAT LOCK(HI-LEX) 1
