Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 31110K63D41 | FLYWHEEL COMP. | 1 |
2 | 31110KZAW21 | FLYWHEEL COMP.(MITSUBA) | 1 |
3 | 31110KZAW01 | FLYWHEEL COMP.(MITSUBA) | 1 |
4 | 31120K14901 | STATOR COMP. | 1 |
5 | 31120K63D31 | STATOR COMP. | 2 |
6 | 90439SB2010 | WASHER, SPECIAL, 24X12X2.3 | 1 |
7 | 90439SB2010 | WASHER, SPECIAL, 24X12X2.3 | 2 |
8 | 9405012000 | NUT, FLANGE, 12MM | 1 |
9 | 960010601600 | BOLT, FLANGE, 6X16 | 1 |
10 | 960010601600 | BOLT, FLANGE, 6X16 | 2 |
11 | 960010602200 | BOLT, FLANGE, 6X22 | 2 |
12 | 960010602200 | BOLT, FLANGE, 6X22 | 1 |
