Scooters Grazia SCV125SJ Frame Seat/luggage box
Ref.No. Part No. Description Oty
1 77115K24900 RUBBER, SEAL 1
2 77200K86D01 SEAT COMP., DOUBLE 1
3 77201K24900 HINGE, SEAT 1
4 77206KG8900 RUBBER, SEAT SETTING 2
5 77215K24900 PIN, SEAT HINGE 1
6 77234K86D00 SPRING, SEAT LOCK 1
7 77235K86D00 CATCH COMP., SEAT 1
8 77240K86D01 CABLE COMP., SEAT LOCK 1
9 77251KPL900 BAG, SERVICE BOOK 1
10 81250K86D00 BOX, LUGGAGE 1
11 81255KZK900 COVER, CARBURETOR MAINTENANCE 1
12 90107KWP900 BOLT-WASHER, 8X16 2
13 90115KW7900 SCREW, VISOR SPECIAL SETTING 2
14 90677KANT00 NUT, CLIP, 5MM 4
15 934040601207 BOLT-WASHER, 6X12 2
16 9405006000 NUT, FLANGE, 6MM 2
17 9410108000 WASHER, PLAIN, 8MM 1
18 9420116180 PIN, SPLIT, 1.6X18 1
19 957010601208 BOLT, FLANGE, 6X12 2
20 17234KCC941 TUBE, AIR CLEANER DRAIN 2
21 90653KWPF00 CLIP, TUBE(B12.5) 2
