Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 51400MJEDB1 | FORK ASSY., R. FR.(SHOWA) | 1 |
2 | 51401MJEDB1 | SPRING, FR. FORK(SHOWA) | 2 |
3 | 51402MGZJ01 | COLLAR, SPRING | 2 |
4 | 51405MB4003 | RING, STOPPER | 2 |
5 | 51410MJEDB1 | PIPE COMP., FR. FORK(SHOWA) | 2 |
6 | 51412MB4003 | RING, BACK UP(SHOWA) | 2 |
7 | 51414MFJA51 | BUSH, GUIDE | 2 |
8 | 51415MFJA51 | BUSH, SLIDER | 2 |
9 | 51416KF0003 | SPRING, FR. REBOUND(SHOWA) | 2 |
10 | 51420MJED01 | CASE, R. BOTTOM | 1 |
11 | 51432MV4003 | PIECE, OIL LOCK | 2 |
12 | 51437MJEDB1 | RING, PISTON(SHOWA) | 2 |
13 | 51440MJEDB1 | PIPE, SEAT(SHOWA) | 2 |
14 | 51447KA4711 | RING, OIL SEAL STOPPER(SHOWA) | 2 |
15 | 51490MKAD81 | SEAL SET, FR. FORK | 2 |
16 | 51500MJEDB1 | FORK ASSY., L. FR.(SHOWA) | 1 |
17 | 51520MJED01 | CASE, L. BOTTOM | 1 |
18 | 90108MR7000 | BOLT, FLANGE, 8X40 | 2 |
19 | 90116KV3701 | BOLT, SOCKET, 8MM(SHOWA) | 2 |
20 | 90544283000 | WASHER, SPECIAL, 8MM(SHOWA) | 2 |
21 | 91251MKAD81 | SEAL, DUST(SHOWA) | 2 |
22 | 91356KF0003 | O-RING, 33.2X2.4 | 2 |
23 | 51454MKAD81 | BOLT, FR. FORK | 2 |
