Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 16574ZG8300 | SPRING, LEVER | 1 |
2 | 50400KTE650ZJ | GRIP, RR*PB396M* ATHLETIC BLUE METALLIC | 1 |
3 | 50400KTE650ZG | GRIP,RR.*R329M*....REBEL RED METALLIC | 1 |
4 | 50400KTE650ZD | GRIP, RR. *NHB63P* PEARL AMAZING WHITE | 1 |
5 | 50400KTE650ZC | GRIP, RR. *NH1* BLACK | 1 |
6 | 50400KTE650ZK | GRIP, RR. *YR333M* SUNSET BROWN METALLIC | 1 |
7 | 50400KTE650ZE | GRIP, RR. *NHA04M* GENY GRAY METALLIC | 1 |
8 | 75581GN8920 | SPRING, LOCK KEY SETTING | 1 |
9 | 77156KTE910 | CABLE, SEAT LOCK | 1 |
10 | 77200KTE651ZA | SEAT ASSY., DOUBLE(VARROC) *TYPE1* | 1 |
11 | 77200KTE652ZA | SEAT ASSY., DOUBLE(TS TECH) *TYPE1* | 1 |
12 | 77204KCC900 | RUBBER A, SEAT SETTING | 2 |
13 | 77206KTE910 | RUBBER, SEAT SETTING | 4 |
14 | 77225KTED02 | LOCK ASSY., SEAT(MINDA) | 1 |
15 | 77225KTE911 | LOCK ASSY., SEAT | 1 |
16 | 77235KTE910 | CATCH COMP., SEAT | 1 |
17 | 77251KPL900 | BAG, SERVICE BOOK | 1 |
18 | 957010601200 | BOLT, FLANGE, 6X12 | 2 |
19 | 957010801800 | BOLT, FLANGE, 8X18 | 4 |
