Motorcycles CB Unicorn CBF150MH Engine Oil pump
Ref.No. Part No. Description Oty
1 15100KRM840 PUMP ASSY., OIL 1
2 15130KRM840 GEAR COMP., OIL PUMP DRIVE (34T) 1
3 15021KREG00 ROTOR SET A, OIL PUMP 1
4 15421KSP910 SCREEN, OIL FILTER 1
5 15430KSP910 ROTOR, OIL FILTER 1
6 15436KRM840 CAP, OIL FILTER ROTOR 1
7 15441KCS650 THROUGH, OIL 1
8 15446107000 SPRING, OIL THROUGH 1
9 15459KWK900 GASKET, OIL FILTER CAP 1
10 9390134120 SCREW, TAPPING, 4X8 1
11 90231KRM840 NUT, LOCK, 14MM 1
12 90432KPTA00 WASHER, 14.2X26X3 1
13 90702KRM840 DOWEL PIN, 8X14 2
14 93700050120A SCREW, OVAL, 5X12 3
15 9425108000 PIN, LOCK, 8MM 1
16 957010603500 BOLT, FLANGE, 6X35 2
