Motorcycles CB Shine SP CBF125MH Frame Front brake panel(drum)
Ref.No. Part No. Description Oty
1 06430KVTD10 SHOE SET, BRAKE(ASK) 1
2 06430KTN700 SHOE SET, BRAKE(JB) 1
3 45100K67900ZA PANEL COMP., FR. BRAKE *NH303M* MAT AXIS GRAY METALLIC 1
4 45133KPL900 SPRING, FR.BRAKE SHOE (ASK)(FOR RR.) 2
5 45134250000 DUST SEAL, BRAKE CAM 1
6 45141KTC900 CAM, FR. BRAKE 1
7 45145096650 INDICATOR, FR. BRAKE 1
8 45410K23900 ARM, FR. BRAKE 1
9 45435KPL900 SPRING, BRAKE ARM RETURN 1
10 9405006000 NUT, FLANGE, 6MM 1
11 9501532001 JOINT B, BRAKE ARM 1
12 9501542000 NUT B, BRAKE ROD ADJUSTING 1
13 957010603200 BOLT, FLANGE, 6X32 1
14 957020603200 BOLT, FLANGE, 6X32 1
