| Ref.No. | Part No. | Description | Oty |
|---|---|---|---|
| 1 | 06430KWP900 | SHOE SET, BRAKE(JB) | 1 |
| 2 | 44711KVT901 | TIRE, FR.(MRF)(90/90-12) | 1 |
| 3 | 45141KWP910 | CAM, FR. BRAKE | 1 |
| 4 | 44301KTR700 | AXLE, FR. WHEEL | 1 |
| 5 | 44311KVT900 | COLLAR, FR. WHEEL SIDE | 1 |
| 6 | 44620KPL900 | COLLAR, FR. AXLE DISTANCE | 1 |
| 7 | 44650KVT940 | WHEEL SUB ASSY., FR. | 1 |
| 8 | 44809KTC900 | WASHER, SPEEDOMETER GEAR | 1 |
| 9 | 44804KVT900 | GEAR, SPEEDOMETER | 1 |
| 10 | 45133KPL900 | SPRING, FR.BRAKE SHOE (ASK)(FOR RR.) | 2 |
| 11 | 45134250000 | DUST SEAL, BRAKE CAM | 1 |
| 12 | 45145KPL900 | INDICATOR, FR. BRAKE | 1 |
| 13 | 45435KPL900 | SPRING, BRAKE ARM RETURN | 1 |
| 14 | 90110KPL900 | BOLT, STUD, 8X22 | 4 |
| 15 | 90306KTE911 | NUT, FLANGE SPECIAL, 12MM (SIMMONDS MARSHALL) | 1 |
| 16 | 90306KST942 | NUT, FLANGE, 12MM (LEO FASTENERS) | 1 |
| 17 | 90309KPL900 | NUT, SPECIAL FLANGE, 8MM | 4 |
| 18 | 90304KPG901 | NUT, U, 8MM | 4 |
| 19 | 90754KPL900 | SEAL, DUST, 20X32X5 | 1 |
| 20 | 90912KPL900 | BEARING, RADIAL BALL, 6201U | 2 |
| 21 | 91253KPL900 | DUST SEAL, 41X60X7 | 1 |
| 22 | 9405006000 | NUT, FLANGE, 6MM | 1 |
| 23 | 957010603200 | BOLT, FLANGE, 6X32 | 1 |
| 24 | 957020603200 | BOLT, FLANGE, 6X32 | 1 |
| 25 | 45010KVT940ZA | PANEL SUB COMP., FR. BRAKE *NH35M* CLOUD SILVER METALLIC | 1 |
| 26 | 44712KVT941 | TUBE, TYRE(MRF)(90/90-12) | 1 |
| 27 | 45410KVT940 | ARM, FR. BRAKE | 1 |
| 28 | 45453KWP911 | JOINT, BRAKE ARM | 2 |
| 29 | 45456KWP910 | SPRING, BRAKE CABLE END | 2 |
| 30 | 45459KWP911 | NUT, BRAKE ADJUSTING | 2 |
