Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 12300KYJ900 | COVER ASSY., CYLINDER HEAD | 1 |
2 | 12341MAT750 | PLATE, PORT(AI) | 1 |
3 | 12391KYJ710 | GASKET COMP., CYLINDER HEAD COVER | 1 |
4 | 15772551000 | CLIP, BREATHER TUBE | 1 |
5 | 18601KEA741 | VALVE COMP., REED(ARAI) | 1 |
6 | 18612KYJ900 | COVER, REED VALVE | 1 |
7 | 90002KGH900 | BOLT, FLANGE, 5X14 | 2 |
8 | 90018KYJ900 | BOLT, HEAD COVER | 2 |
9 | 90543MV9670 | RUBBER, MOUNTING | 2 |
10 | 9430110160 | DOWEL PIN, 10X16 | 1 |
