Ref.No. | Part No. | Description | Oty |
---|---|---|---|
1 | 06431MA3405 | SEAL SET, PISTON | 2 |
2 | 06451MZ2405 | SEAL SET, PISTON | 1 |
3 | 06455KYJ912 | PAD SET, FR | 1 |
4 | 43352568003 | SCREW, BLEEDER(NISSIN) | 2 |
5 | 43353461771 | CAP, BLEEDER | 2 |
6 | 45107MAJG41 | PISTON A, 22X27 | 1 |
7 | 45108KYJ911 | SPRING, PAD | 1 |
8 | 45111MAJG41 | RING, STOPPER | 1 |
9 | 45112MZ2006 | RETAINER, BRACKET | 1 |
10 | 45131ML7921 | BOLT A, PIN | 1 |
11 | 45132166016 | BOOT, PIN BUSH(NISSIN) | 1 |
12 | 45133MA3006 | BOOT B | 1 |
13 | 45161KYJ610 | CLAMPER, SENSOR CORD | 1 |
14 | 45215MBTD51 | PIN, HANGER | 1 |
15 | 45218MAJG41 | PISTON B, 27X35 | 2 |
16 | 45250KYJ911 | CALIPER SUB ASSY., R. FR. | 1 |
17 | 45250KYJG91 | CALIPER SUB ASSY., R. FR. | 1 |
18 | 45290MERR81 | BRACKET SUB ASSY., R. FR. | 1 |
19 | 90131KYJ710 | BOLT, FLANGE, 8X32 | 2 |
20 | 960010601007 | BOLT, FLANGE, 6X10 | 3 |
