Scooters Activa125 SCV125G Frame Front cover
Ref.No. Part No. Description Oty
1 50301K24900 STAY, C.D.I. 1
2 50302K24910 STAY, MASTER CYLINDER CUP 1
3 50623K24900 COVER, FR. UNDER 1
4 64200K24920ZA COVER SET, FR. UPPER(WL) *TYPE4* 1
5 64200K24920ZB COVER SET, FR. UPPER(WL) *TYPE3* 1
6 64200K24920ZC COVER SET, FR. UPPER(WL) *TYPE2* 1
7 64200K24920ZD COVER SET, FR. UPPER(WL) *TYPE1* 1
8 64302K24900 COVER, FR. LOWER 1
9 64303K24920 STAY, FR. NUMBER PLATE 1
10 64304K24900ZZ COVER, R. FR. 1
11 64305K24900ZZ COVER, L. FR. 1
12 64306K24900 LOUVER, R. FR. 1
13 64307K24900 LOUVER, L. FR. 1
14 81131K24911ZA COVER, INNER *NH1* BLACK 1
15 81131K24901ZA COVER, INNER *NH1* BLACK 1
16 84703425000 RUBBER, TAILLIGHT MOUNTING 2
17 90111KWP900 BOLT, INNER COVER 1
18 90344KRB900 NUT, CLIP, 5MM 12
19 90344KRP900 NUT, CLIP, 5MM 4
20 90601SJA003 CLIP, SNAP FITTING 4
21 90677KANT00 NUT, CLIP, 5MM 4
22 90677KANT00 NUT, CLIP, 5MM 2
23 938910501208 SCREW-WASHER, 5X12 4
24 938910501208 SCREW-WASHER, 5X12 2
25 9390325380 SCREW, TAPPING, 5X16 14
26 9390334480 SCREW, TAPPING, 4X16 4
27 9405006080 NUT, FLANGE, 6MM 2
28 957010601208 BOLT, FLANGE, 6X12 4
29 957010602507 BOLT, FLANGE, 6X25 2
